Geogrid is a polyester, flexible, high-performance geogrid used in soil reinforcement and other civil engineering applications. Geogrid is manufactured in our GAI-LAP accredited factory using a high-grade polyester yarn with special, high-tenacity, and low-creep properties knitted into a network and then coated with a proprietary coating. It is differentiated from other geogrids with its superior elongation and stress-strain values, and with a design life of 120 years! Our Geogrid has a range of ultimate tensile strengths ranging from 20 kN to 800 kN for varying design applications. We customize the lengths and widths depending on the project requirements.
Geogrid is manufactured in one of the few GAI-LAP accredited factories in the world assuring our customers that we deliver quality products measured against global benchmarks of industry excellence.
TanRu is specialized in the manufacture of PET geogrid. We choose high performance PET filament fiber as raw material and warp knitted at German Karl Mayer machines. Geogrid is aligned structure. There is no bending along the weft yarn and warp yarn. Junction is stitched with high strength fiber to make it solid and fulfill its mechanics performance and integrity. Different kinds of PET warp knitted material are available according to technological requirements.
Warp knitted PET geogrid is high tensile strength, low elongation, resistance to tear, UV, aging, abrasion and corrosion, can be designed to be different strength uniaxially or biaxially. It is used to improve the shear strength of soil and increase the overall bearing capacity of soil.
1. high tensile strength (up to 1600kn/m)
2. low elongation (≤10%)
3. low creep, low installation damage
4. resistance to corrosion and aging
5. good interlocking ability
6. high molecular, less carboxyl end group, and durable
7. different coating is available
| Item Spec | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | TRPG | |
| 3030 | 5050 | 8080 | 100100 | 120120 | 150150 | 200200 | 300300 | 6030 | 8030 | 10030 | 12030 | 15030 | 20030 | 40050 | ||
| Weft | 30 | 50 | 80 | 100 | 120 | 150 | 200 | 300 | 60 | 80 | 100 | 120 | 150 | 200 | 400 | |
| Tensile strength | ||||||||||||||||
| ≥KN/m | Warp | 30 | 50 | 80 | 100 | 120 | 150 | 200 | 300 | 30 | 30 | 30 | 30 | 30 | 30 | 50 |
| Elongation ≤ | 13% | |||||||||||||||
| Mesh size（mm） | 25.4×25.4 or 50.8x50.8 or 76.2x76.2 | |||||||||||||||
